APPENDIX “E”– ROSETTE INTERFACE
IDRONAUT – Brugherio (MB) OCEAN SEVEN 310 CTD 01-2019
112
E.5 TEST ROSETTE INTERFACING
Once configured, it is possible to test the Rosette interfacing and Rosette operations by means of two
functions which are automatically added to the Service Menu. Therefore, after the Rosette configuration,
the service menu appears as:
OCEAN SEVEN 310 - ID:0000000 {USR}(1.1_00 06/17)Oct 01 13:06:15.13 2016
Service menu
<0>[SVUP]-Leave the service menu
<1>[CONF]-Configuration
<2>[DIAG]-Diagnostics
<3>[RAWC]-Raw data acquisition in counts (bit)
<4>[RAWM]-Raw data acquisition in mV
<5>[FIRE]-Bottle fire
<6>[HOME]-Rosette to home position
cmd>
The two new commands: FIRE and HOME allow the operator to respectively fire a bottle (close a bottle)
and return the bottle closing arm to the resting position.
