No. of digits after the dot Number of digits used to show the fractional part of the acquired data for
this sensor.
Do you want to store it ? It is possible to acquire and not show the value or to acquire and show it.
Do you want to show data ?It is possible to acquire and not store in memory acquired data.
Data processing method: Kind of algorithm used to convert ADC counts reading from a sensor into
engineering values. Predefined values are: (0)Counts, (1)mV,
(2)Proprietary&UNESCO, (3)Polynomial interpolation, (4)Linear
interpolation.
Mux. Channel Analogue input can be 0..16. The 255 value is used to identify a derived
parameter like salinity, which does not belong to a single sensor.
Mux. Delay Delay in ms to be spent during acquisition to wait for the stabilization of the
sensor pre-amplifier before acquiring.
6.1.3.9 List of the common sensor logical codes
Pressure 0 Temperature 1 Conductivity 2
Salinity 4 Oxygen ppm 5 Oxygen % 6
pH 7 Fluorometer 11 Transmissomenter 12
Sound Velocity 16 Density (SigmaT) 22 Turbidity meter 24
PAR 25.
Note
The complete list of the sensor logical codes can be found in the document describing the ocean seven 3xx data
transfer protocol.
6.1.3.10 Change date & time
Probe RTC date and time can be configured.
Enter Date&Time: 05/01/2007 13:47:26 06
The probe date and time can be modified. At the end of this command, the “Configuration Menu” is
shown.
Note The day of the week is numbered starting from Sunday (1).
6.1.3.11 External systems
The external equipment interfaced by the probe through digital, analogue or serial interface I/O can be
configured.
OCEAN SEVEN 310 - ID:0617002 {USR}(1.1_00 06/17)Oct 01 12:47:13.58 2016
--- Auxiliary setup ---
Aux.#1,select:(0)None,(1)Trilux,(2)Wetlab ECO
Aux.#1:0
Aux.#2-Rosette:(0)No,(1)GO1018,(2)SBE32c,(3)MISS
Aux.#2:0
Aux.#3 Select:(0)None,(1)miniSVS,(2)IDRO-DO2
Aux.#3:0
Auxiliary system/sensor configuration parameter are described in the appendix dedicated to describe
the interfaced sensor/system.
