DM-F Series Monitor
Page 8
1.8 Technical Specifications
4Table 1-2 shows the DM-F series technical specifications.
Model DM-F65A DM-F08A DM-F12A
DM-F15A
DM-F17A DM-F19A DM-F22A DM-F24A
LCD Display 6.5” (4:3) 8” (4:3) 12” (4:3) 15” (4:3) 17” (5:4) 19” (5:4) 21.5” (16:9)
24” (16:9)
Max. Resolution 640x480 800x600 1024 x768
1024 x768
1280x1024 1280x1024 1920x1080 1920x1080
Brightness
(cd/m²)
800 500 600 450 350 350 250 250
Contrast Ratio 600:1 500:1 700:1 800:1 1000:1 1000:1 1000:1 3000:1
LCD Color 16.2M 262K 16.2M 16.2M 16.7M 16.7M 16.7M 16.7M
Pixel Pitch (mm) 0.207 x
0.207
0.0675 x
0.2025
0.24 x
0.24
0.29 x
0.29
0.26 x
0.26
0.294 x
0.294
0.25 x
0.25
0.28 x
0.28
Viewing Angle
(H/V)
160°/140° 140°/120° 160°/140°
160°/150°
170°/160° 170°/160° 170°/160° 178°/178°
Backlight MTBF
(Hrs)
50,000 50,000 50,000 70,000 50,000 50,000 30,000 30,000
Touchscreen 5-wire resistive type 5-wire resistive type or projected capacitive type Projected capacitive type
Touch Controller
Penmount 6000
Resistive type: Penmount 6000
Projected capacitive type: EETI EXC7200
EETI
EXC3000
AD Board AV-60381 AV-60381 AV-6038 AV-6038 AV-6038 AV-6038 AV-6038 AV-6038
OSD Button 5-key 5-key 7-key 7-key 7-key 7-key 7-key 7-key
Smart OSD Yes Yes Yes Yes Yes Yes Yes Yes
Dimensions (mm)
(W x H x D)
191.8 x
154.36 x
42.88
222.2 x
182.2 x
42.7
322.2 x
262.2 x
40.5
378.5 x
303 x
43.2
408.4 x
341.4 x
49.3
447.4 x
372.4 x
49.57
550.4 x
358.4 x
49.1
600 x
382 x
49.4
Cutout Dimensions
(W x H) (mm)
180 x 140 206 x 154 305 x 245
361 x 286
391 x 324 430 x 355 532 x 340 577 x 359
Weight (kg)
(Net/Gross)
1.1/2.6 1.33/4.5 2.7/4.9 3.5/5.5 4.4/7.1 5.4/8.4 6.3/9.6 7.6/10.9
Enclosure Color Black C Black C Black C Black C Black C Black C Black C Black C
Front Frame Aluminum Aluminum Aluminum
Aluminum
Aluminum Aluminum Aluminum Aluminum
Rear Cover Sheet
Metal
Sheet
Metal
Sheet
Metal
Sheet
Metal
Sheet
Metal
Sheet
Metal
Sheet
Metal
Sheet
Metal
VESA Mount 75 75 100 100 100 100 100 100
