6.3.3 LVDS Connector (LVDS1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 GND
3 A0P_C 4 A0M_C
5 A1P_C 6 A1M_C
7 A2P_C 8 A2M_C
9 CLK1P_C 10 CLK1M_C
11 A3P_C 12 A3M_C
13 GND 14 GND
15 A4P_C 16 A4M_C
17 A5P_C 18 A5M_C
19 A6P_C 20 A6M_C
21 CLK2P_C 22 CLK2M_C
23 A7P_C 24 A7M_C
25 GND 26 GND
27 VCC 28 VCC
29 VCC 30 VCC
Table 6-13: LVDS Connector (LVDS1) Pinouts
6.3.4 OSD Keypad Connector (KEYPAD1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 +5V_OSD(NC) 2 +12V(NC)
3 Left 4 Auto
5 Right 6 Power
7 Menu 8 Led_GREED (UP)
9 Down (NC) 10 Led_RED
11 GND 12 +3.3V_DVDD(NC)
Table 6-14: OSD Keypad Connector (KEYPAD1) Pinouts
