6.3.12 Power Input Setting Jumper (JP4)
DESCRIPTION
Short 1-3, 2-4 +12 V from power jack (PRW1)
Short 3-5, 4-6
Input with external connector
(external power module is needed)
Table 6-22: Power Input Setting Jumper (JP4) Pinouts
6.3.13 Touchscreen Type Select Jumper (JP1)
DESCRIPTION
1 5-wire touchscreen
2 4-wire/8-wire touchscreen
Table 6-23: Touchscreen Type Select Jumper (JP1) Pinouts
