IES Wallbox G3 - Internal View - Upper Level

www.ies-synergy.com
Installation Manual DIM016055-EN
10
Internal view - upper level
1
2
3
4
5
6
7
8
9
10
11
12
13
Position Description
1 Antennas
2 External fans for heat exchanger
3 Hood stand
4 Key locker
5 Input plate + cable gland
6 Emergency stop button
7 Heat exchanger
8 Extractor fan
9 Power module lid
10 CCU board
11 Distribution board
12 Output plate + cable gland
13 Key locker
Note: May change depending on version or technical modification
