5. Specification
Main supply
The charging station can be connected to several mains supplies as detailed on following tables.
3-phase P1/P2/P3 + N + GND 3x380-480V
AC
Mains supplies 3-phase P1/P2/P3 + N + GND 3x380-480V
AC
(24kW)
Mains 3-phase voltage range V
AC
380-480 V
AC
± 10%
Earthed electrical system TT or TN
Frequency range f 50/60 Hz ± 10%
Nominal input current I
AC
40-32A Nom
Maximum input current I
AC
45A Max
Power Factor PF 0,99 Nom
Efficiency ɳ 95 % Nom
Harmonic current @ nominal network voltage THDi < 13 % Max
3- phase P1/P2/P3 + GND 3x208-240V
AC
Mains supplies 3- phase P1/P2/P3+GND 3x208-240V
AC
(24kW)
Mains 3-phase voltage range V
AC
208-240 V
AC
± 10%
Earthed electrical system TT, TN or IT
Frequency range f 50/60 Hz ± 10%
Nominal Input current I
AC
72-63A Nom
Maximum Input current I
AC
80A Max
Power Factor PF 0,99 Nom
Efficiency ɳ 95 % Nom
Harmonic current @ nominal network voltage THDi < 13 % Max
Single-phase P + N + GND 1x220-240V
AC
Mains supply single-phase P + N + GND 1x220-240V
AC
(24kW)
Mains single-phase voltage range V
AC
220-240 V
AC
± 10%
Earthed electrical system TT or TN
Frequency range f 50/60 Hz ± 10%
Nominal Input current I
AC
123-112A Nom
Maximum Input current I
AC
140A Max
Power Factor PF 0,99 Nom
Efficiency ɳ 95 % Nom
Harmonic current @ nominal network voltage THDi < 13 % Max
3-phase P1/P2/P3 + N + GND 3x380-400V
AC
with power metering
(1)
Mains supplies 3-phase P1/P2/P3 + N + GND 3x380-400V
AC
(24kW) with power metering
(1)
Mains 3-phase voltage range V
AC
380-400 V
AC
± 10%
Earthed electrical system TT or TN
Frequency range f 50/60 Hz ± 10%
Nominal input current I
AC
40-32A Nom
Maximum input current I
AC
45A Max
