AC input configuration
Each connecting point should be individually considered and protected by a residual current device (RCD) (the
charging station ensure only supplementary protection by fuses on each line).
Electrical input should be :
1. 3-phase in wye configuration with neutral 3x380-480V
AC
For AC input connection, see step 5A
2. 3-phase in wye or delta configuration without neutral 3x208-240V
AC
For AC input connection, see step 5B
3. Single phase 220-240V
AC
For AC input connection, see step 5C
4. 3-phase in wye configuration with neutral 3x380-480V
AC
with power metering
The values returned by this card are given as an indication and can not be used to make payment.
For AC input connection, see step 5D
I DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
• Be sure the supply power is off before starting installation
• Make sure nobody can switch on power during installation
Failure to follow these instructions will result in death or serious injury.
To Next Page
