IES Wallbox G3 - Technical Specification

www.ies-synergy.com
Installation Manual DIM016055-EN
13
Mains supplies 3-phase P1/P2/P3 + N + GND 3x380-400V
AC
(24kW) with power metering
(1)
Power Factor PF 0,99 Nom
Efficiency ɳ 95 % Nom
Harmonic current @ nominal network voltage THDi < 13 % Max
Technical specification
Internal AC input protection
Inrush current limitation per phase I
INRUSH LIMIT
< 3 x I
AC
Max
Rated Current Fuse (per module) I
BREAK
Rating 80A typ
Breaking capacity of fuses I
BREAK
Capacity 80 000A Max
Max earth leakage current I
LEAKAGE
< 3,5 mA Max
Emergency button connection Yes
Overvoltage (IEC60664-1) OV III
Insulation protection Class (IEC60664-1) Class I
Internal DC Output
Output voltage
V
DC
_max 530 V
DC
Max
V
DC
_min 150 V
DC
Min
Output current
I
DC
_max 65A
(2)(3)
Max
I
DC
_min 1,5A Min
Max Output Power P
OUT
24kW Max
Output connector (charging station side) Permanent mounting
Car Plug coupler COMBO 2 or CHAdeMO
Output cable length - 4 Meters
Internal DC output protection
Hardware and software short circuit protection Yes
Software and Hardware over voltage protection adjustable +10% max
Over temperature protection - 70 °C
Reverse polarity protection Yes
DC output Contactor Yes (2 poles)
Rated Current Fuse (output) I
FUSE
125 A
Galvanic isolation V
input / output
5200 V
DC
Max time for DC line discharge < 60V T
<60V
1 s
Embedded Insulation device
Response time (tan)
< 3sec. for asymmetrical fault
< 62sec. for symmetrical fault
Self test time At power on and every 60s during charge
Internal resistance Ri of the measuring circuit
1.5Mohms permanent
750Kohms continuous measurement
300Kohms during simultaneous switching measurement
Measurement method Continuous and switching measurement resistor method
Measuring current Im < 1,4mA at RF=0
Measurement range (Ran) 20Kohms…300Kohms
Relative uncertainty ±15%
