14
Embedded Insulation device
Line L+/L- Voltage (Un) DC 150V…530V
System leakage capacity Ce
≤ 1µF : response value (Ran) and time (tan) are not guar-
anteed for capacity above 1µF
Parallelization
I Warning: Do not connect the insulation monitor de-
vice (IMD) in parallel !!
Response value (Ran) and time (tan) are not guaranteed.
General & dimensions
External dimensions (mm) H x W x D 860 x 507 x 250 mm
Weight (without cable, or bracket) kg 66kg Max
Type of installation
Mounting on a wall or on a pedestal with
proper fixation point
Fixation points 8 screws for wall mounting
Protection type (EN60529) IP IP54
Cooling systems
Heatsink with forced air flow by fans IP55
without air filter
Noise (1m, all direction) Db(A) 65dbA (1m)
Climatic & Environment constraints
Operating temperature (with derating) -25°C to +55°C
(4)
Storage temperature -25°C to +60°C
Relative humidity RH 10% to 95%
Installation altitude Alt 2 000m Max
Norms & standards
EC Low voltage EC directive (LVD) 2014/35/EU
EC Electromagnetic Directive (EMC) 2014/30/EU
Radio Equipment Directive (RED) 2014/53/EU
Electric vehicle conductive charging system part 1
General requirement
IEC 61851-1
Electric vehicle conductive charging system part 23
DC Electric vehicle charging station
IEC 61851-23
EMC requirement for OFF board electric vehicle charging
system
IEC 61851-21-2
Insulation Monitor Device (IMD) IEC 61557-1 & IEC 61557-8
RoHS 2015/863/EU
Declaration of conformity CE
(5)
Yes
(1)
EC approval pending.
(2)
Max output current will be adapted versus maximum carrying current of the vehicle plug.
(3)
Output current can be even reduced with the power derating versus temperature.
(4)
Potential derating above 35°C.
(5)
CE marking affixed on the product attest the conformity of the product with applicable requirements of rele-
vent Community harmonization legislation.
