IES Wallbox G3 - Open the Side Door; Unlock Wallbox Bracket

www.ies-synergy.com
Installation Manual DIM016055-EN
19
1. Remove the screw (1) on side door - position 1
2. Remove the side panel
1
Open the side door
3
1. Remove the nuts (3) on bracket’s studs - position 1
1
Unlock Wallbox bracket
4
