1. Lift the charging station onto its mounting bracket.
Note: Due to the charger weight, two people or lifting
equipment are required to lift and handle the charging
station.
Install Wallbox
2
1. Tighten the nuts (3) on bracket’s studs - position 1
1
Lock the Wallbox on its bracket
3
