Table of content
1. Safety notes 5
Notice 5
Please note 5
2. About the manual 6
Purpose of this manual 6
Document scope 6
Related documents 6
User comments 6
3. General Safety instructions 7
4. Overview 8
External view 8
Internal door view 9
Internal view - upper level 10
Internal view - lower level 11
5. Specification 12
Main supply 12
3-phase P1/P2/P3 + N + GND 3x380-480V
AC
12
3- phase P1/P2/P3 + GND 3x208-240V
AC
12
Single-phase P + N + GND 1x220-240V
AC
12
3-phase P1/P2/P3 + N + GND 3x380-400V
AC
with power metering
(1)
12
Technical specification 13
Compliance 15
Derating 15
6. Handling and storage instructions 16
Storage 16
Transport 16
Equipment Handling 16
7. Installation 17
Installation rules 17
Unscrew lid of crate 18
Unpacking Wallbox 18
Unpacking 18
Open the side door 19
Unlock Wallbox bracket 19
Remove Wallbox bracket 20
Wall mounting 21
Install Wallbox bracket 21
Install Wallbox 22
Lock the Wallbox on its bracket 22
Close the side door 23
Connector’s holster installation 24
Connector holster installation 24
Hold the connector on holster 25
Switch off external power supply 26
Electrical connection 26
Checking the Electrical Requirements 26
Grounding Instructions 26
Open the door 27
Remove Input plate with cable gland 27
