ifm Operating Instructions IO-Link Master with Profinet interface StandardLine 8 Ports IP 65 / IP 67 (AL1102) 2017-05-31
Configuration
>
8.2 LR DEVICE: Configure the device
Set-up .....................................................................................................................................................33
Configure communication profile ............................................................................................................34
Configure the Ethernet interface ............................................................................................................35
Configure the interface to the SmartObserver........................................................................................36
Set the operating mode of the IO-Link ports ..........................................................................................37
Set device validation and data storage ..................................................................................................38
Reset IO-Link master to factory settings ................................................................................................40
22402
The IO-Link master and the IO-Link devices connected to the AL1102 can be configured with the ifm
software LR DEVICE.
Further information about operation and functions of the LR DEVICE parameter setting
software:
► Use the help function of the parameter setting software LR DEVICE!
In order to configure the AL1102 with the LR DEVICE.
► Put AL1102 into operation (→ Set-up (→ p. 33)).
► Under [ONLINE]: Click on the AL1102.
> LR DEVICE shows the following sections:
Section
Functions
[All]
all available functions
[Network]
→ Configure the Ethernet interface (→ p. 35)
[LineRecorder]
→ Configure communication profile (→ p. 34)
→ Configure the interface to the SmartObserver (→ p. 36)
[Port x]*
→ Set the operating mode of the IO-Link ports (→ p. 37)
→ Set device validation and data storage (→ p. 38)
[Setup]
→ LR DEVICE: Read device information (→ p. 57)
→ Reset IO-Link master to factory settings (→ p. 40)
→ Reboot the device (→ p. 58)
* ... x = 1...8
