8.2.1 Set-up
12759
On delivery, the AL1102 is configured with the → Factory settings (→ p. 62)
Before configuration with the LR DEVICE parameter setting software, the user must put the device into
operation. During set-up, the IP settings are configured via the Profinet interface (X21/X22).
In order to put the device into operation with LR DEVICE:
Prerequisites
> The device is configured with the factory settings.
> The device is properly connected with the LR DEVICE laptop/PC via the Profinet interface.
> LR DEVICE is started
1 Scan network
► Scan network for new IO-Link masters.
> The following information is given under [ONLINE]:
- Article number (AL1102)
- MAC-ID of the device
2 Set network parameters
► Under [ONLINE]: Click on [AL1102].
> LR DEVICE shows all current network settings
► Set the following parameters as required:
Parameters
Description
Possible values
[IP address]
IP address of the device
e.g. 172.18.65.50
[Subnet mask]
Subnet mask of the IP network
e.g. 255.255.255.0
[IP gateway address]
IP address of the network gateway
e.g. 172.18.65.0
[Profinet name]
Device name in the Profinet parameter setting software
► Observe the note!
When giving the Profinet name, the following restrictions apply:
 Permitted characters:
– Lower case a-z
– Numbers 0-9
– Separators: Point, minus sign
 Restrictions:
– The name may not end with a point or minus sign
– The name may not begin with a number
– The minus sign may not be directly before or after a point
► Write the changed values to the device.
> LR DEVICE stores the changed values on the device.
If successful:
> In the [ONLINE] area: Under [Geräte], the Profinet name of the AL1102 appears.
> LR DEVICE shows options for device configuration.
