ifm Operating Instructions IO-Link Master with Profinet interface StandardLine 8 Ports IP 65 / IP 67 (AL1102) 2017-05-31
Configuration
>
8.6.3 Configure IO-Link devices
1860
Symbol / function
block
Description
Remarks
IO_LINK_DEVICE /
FB5001
Acyclic access to the parameters of an IO-Link
device
Input parameters:
 CAP: Access point for function
AL1102: 0xB400
 PORT: HW-ID: Slot/sub-slot of the IO-Link port
with connected IO-Link device
Port X01: 1
Port X02: 2
Port X03: 3
Port X04: 4
Port X05: 5
Port X06: 6
Port X07: 7
Port X08: 8
 IOL_INDEX and IOL_SUBINDEX: depends on
the IO-Link device (→ operating instructions of
the IO-Link device)
IOL_CALL /
FB1
Acyclic access to the parameters of an IO-Link
devices (obsolete)
→ IO_LINK_DEVICE
