ifm Operating Instructions IO-Link Master with Profinet interface StandardLine 8 Ports IP 65 / IP 67 (AL1102) 2017-05-31
Configuration
>
8.2.3 Configure the Ethernet interface
22404
To set the parameters of the Profinet interface (X21/X22):
► Select the [Network] menu.
> The page shows the current settings.
► Set the following parameters as required:
Parameters
Description
Possible values
[IP address]
IP address of the device
e.g. 172.18.65.50
[Subnet mask]
Subnet mask of the IP network
e.g. 255.255.255.0
[IP gateway address]
IP address of the gateway
e.g. 172.18.65.1
[Profinet name]
Name of the device in the Profinet network*
e.g. al1xxx
[MAC address]
MAC address of the device
The value is fixed
* ... observe the restrictions concerning the naming conventions (→ Set-up (→ p. 33))!
► Store changed values on the device.
