ifm Operating Instructions IO-Link Master with Profinet interface StandardLine 8 Ports IP 65 / IP 67 (AL1102) 2017-05-31
Operation
>
9.2.1 Web interface: Read device and diagnostic information
12744
In order to read the diagnostic information about the current device status via the web interface:
► Connect laptop/PC and AL1102 via the Ethernet internet.
► Start web browser.
► Enter the following into the address field of the browser: and confirm with [ENTER]:
<IP address of the device>
> Web browser shows the web interface of the device.
> The page shows the following data:
 Table with connected IO-Link devices
Name
Description
[Port]
Number of the IO-Link interface
[Mode]
Operating mode of the IO-Link interface
[Comm. Mode]
Baud rate of the IO-Link interface
[MasterCycleTime]
Cycle time
[Vendor ID]
ID of the manufacturer of the IO-Link device
[Device ID]
ID of the IO-Link device
[Name]
Article number of the IO-Link device
 For ifm articles: This article number is stored along with a link to the produkt page on
the ifm website.
[Serial]
Serial number of the IO-Link device
[LR Interval]
Cycle time for the communication with the SmartObserver
 Version information of the installed firmware components
Name
Description
[Firmware version]
Firmware version
[FirmwareCN Version]
Version of the firmware container
[Bootloader Version]
Version of the boot loader
[NETX Firmware Version]
Version of the Profinet firmware
 Diagnostic information of the device
Name
Description
[Current]
Current (in mA)
[Voltage]
Voltage (in mV)
[Short Circuit]
Number of detected short circuits
[Temperature]
Device temperature (in °C)
The page of the device is constantly updated. This is why the data is always up-to-date.
>
