Configuration
Further information about the parameters of the Profinet modules: → Parameters of the IO-Link
ports (→ p. 70)
► Click on [Add] to save the changes.
> Changed settings are applied.
>
8.4.5 Configure the Profinet interface
22761
In order to configure the Ethernet interface of the AL1102:
Prerequisites
> AL1102 is correctly integrated in the Profinet project (→ Add the device to the Profinet network (→ p. 45)).
1 Open object characteristics
► Start the application "HW Konfig"
► Click on AL1102.
► Select [Target System] > [Ethernet ...] > [Edit Ethernet Users].
> [Edit Ethernet Users] window appears.
2 Search AL1102
► Click on [Durchsuchen ...] button.
> [Browse Network] window appears.
► Click on [Start] button.
> STEP 7 browses the Profinet network for devices.
> List shows found devices.
► Select AL1102 in list and click [OK] to adopt the device.
> The [MAC address] shows the MAC address of the AL1102
3 Set IP address and network mask
► Click on the [Use IP parameters] selection field in group [Set IP configuration].
► Enter the required IP address in the [IP address] field.
► Enter the required subnet mask in the [Subnet mask] field.
4 Assign device names
► Enter the required Profinet name in the [Device name] field.
► Click on the [Assign Name] button.
> STEP 7 assigns the selected name to the AL1102.
► Click on the [Close] button to close the window.
