8.2 Explanation of the menu
SP1/rP1 Maximum / minimum value for volumetric flow�
ImPS Pulse value�
ImPR
Pulse repetition active (= pulse output) or not active (= function preset meter)�
OU1
Output function for OUT1 (volumetric flow or consumed quantity):
- Switching signal for limit values: hysteresis function or window function,
normally open or normally closed�
- Pulse or switching signal for quantity meter�
OU2
Output function for OUT2 (volumetric flow or temperature):
- Switching signal for limit values: hysteresis function or window function,
normally open or normally closed�
- Analogue signal: 4-20 mA [I] or 0-10 V [U]�
As an alternative: configure OUT2 (pin 2) as input for the external reset
signal: setting: [OU2] = [InD]�
SP2/rP2 Maximum / minimum value for volumetric flow or temperature�
ASP Analogue start value for volumetric flow or temperature�
AEP Analogue end value for volumetric flow or temperature�
DIn2 Configuration of the input (pin 2) for meter reset�
EF Extended functions / opening of menu level 2�
HI Maximum value memory for volumetric flow�
LO Minimum value memory for volumetric flow�
FOU1 Behaviour of output 1 in case of an internal fault�
FOU2 Behaviour of output 2 in case of an internal fault�
dSt Start-up delay�
P-n Output logic: pnp / npn�
dAP Measured value damping / damping constant in seconds�
rTo Meter reset: manual reset / time-controlled reset�
diS Update rate and orientation of the display�
Uni
Standard unit of measurement for volumetric flow: litres/minute or cubic
metres/hour�
SELd
Standard process category of the display: volumetric flow value / meter
count / medium temperature�
SEL2
Standard process category for evaluation by OUT2:
- Limit value signal or analogue signal for volumetric flow�
- Limit value signal or analogue signal for temperature�
res Restore factory setting�
