1. UNLOADING
The device should be transported in vertical position, and it should be properly secured and packed. The manufacturer
ships the device on a special wooden platform, secured with cardboard angle sections and foil.
2. PROPERTIES OF THE DEVICE
2.1. Purpose
LUZON is a universal cooling device used to store and display a wide assortment of grocery products in singular pac-
kages, previously cooled to storage temperature. There is also a DEEP version of the case (ventilated, evaporator at
the front, horizontal display shelves). Our display cabinets ensure universal and efcient display area for all types of
commercial and gastronomic units. Guaranteed temperature inside the display cabinet equals +2ºC/+8ºC with ambient
temperature of +15ºC/+25ºC and relative air humidity of up to 60%.
2.2. Description of the device
LUZON cases have static cooling, while LUZON DEEP have dynamic cooling. LUZON display cabinets have dynamic
or static cooling. All types are equipped with automatic defrosting and electronic thermostat optionally cooperating with
temperature recording module enabling to record and signal too low and too high temperature within the device. There is
also an option with automatic condensate evaporation. Together with corned display cabinets, they may be connected
in sequences. “LUZON” display cabinets may be ordered in two versions: with internal aggregate or to be connected to
central aggregate (mod/C). “LUZON” display cabinets are equipped with storage chamber. “SAMOS” display cabinet is
available in stationary or moving version. Our devices are made according to modern technologies and have all certica-
tes required by law.
Contents List of Figures
1. UNLOADING 15
2. PROPERTIES OF THE DEVICE 15
2.1. Purpose 15
2.2. Description of the device 15
2.3. Technical data 16
3. PREPARING THE DEVICE FOR EXPLOITATION 17
3.1. Requirements concerning the place of installation 17
3.2. Connection and actuation 17
4. EXPLOITATION 21
4.1. Temperature regulation 21
5. MAINTENANCE 21
5.1. Cleaning and maintenance 21
6. SERVICE 24
6.1. Fault identication and repair 24
6.2. Service 25
7. THERMOSTAT SERVICE 26
7.1. „IGLOO” thermostat 26
7.2. „CAREL” thermostat 27
This sign signies information of particular meaning for user security and for proper device
exploitation.
Fig. 1. Construction of the device 16
Fig. 2. Removing the wooden platform 17
Fig. 3. Wheel system, moving system 18
Fig. 4. Installation of glass components and aluminium lamp 19
Fig. 5. Assembly/disassembly of night shutters 19
Fig. 6. Condensate container (version without evaporator) 20
Fig. 7. Overow (version with evaporator) 20
Fig. 8. Control panel of the device 20
Fig. 9. Cleaning the condenser 22
Fig. 10. Changing the uorescent lamp 22
Fig. 11. Data plate 25
Fig. 12. „Igloo” thermostat control panel 22
Fig. 13. Carel” thermostat control panel 23
