18
i
①
Shoulder belt hook
$WWDFKHVDQRSWLRQDOVKRXOGHUEHOW
②
VF connector
Connects the VF cable
③
VF CONNECTOR LOCK button
Prevents the VF connector from being disconnected. To disconnect the VF cable, hold
down this button.
④
VF CABLE clamp
Secures the VF cable.
⑤
RET-2/MIC button
The RET-2 switch function or INTERCOM MIC switch function is allocated to this button.
The button selects the function or turns ON/OFF the function.
●
When set to RET-2
7KHYLHZ¿QGHULPDJHLVVZLWFKHGIURPWKHFDPHUDLPDJHWR5(7LPDJHZKLOHWKLV
button is pressed.
●
When set to INTERCOM MIC
Turns the intercom microphone ON/OFF when the INTERCOM FRONT VR SELECT
VZLWFKRQWKHUHDURIWKHFDPHUDLVVHWWR(1*RU352'7KHLQWHUFRPPLFURSKRQHLV
turned ON while this button is pressed.
⑥
RET-1 button
6ZLWFKHVWKHYLHZ¿QGHULPDJHIURPWKHFDPHUDLPDJHWR5(7LPDJH7KHYLHZ¿QGHU
image is switched to the RET-1 image while this button is pressed.
⑦
Breaker
$EUHDNHU$IRUWKHFDPHUD
⑧
M
IC CABLE clamp
Secures a microphone cable.
⑨
CAMERA connector
&RQQHFWVWKHFDPHUDDQG%6ZLWKD¿EHUFDEOH
⑩
CAMERA CABLE clamp
6HFXUHVWKH¿EHUFDEOHPPGLDPHWHU
⑪
MEMORY CARD slot
$VORWIRUWKHPHPRU\FDUG6'FDUGXVHGWRVWRUHDQGUHFDOOVHWXSGDWD:KHQXVLQJWKH
memory card, carefully insert the card in the slot until you hear a clicking sound.
When removing the card, carefully push in the upper part of the inserted card until you hear
a clicking sound. The card will move out, making it possible to remove it.
When not using the memory card, attach the cover to prevent dust from accumulating.
When storing or retrieving data, the access indicator on the side of the the slot is lit. Do not
remove the card if the access indicator is lit.
This could destroy the data on the card, also could destroy the camera data.
Reference:
The functions are allocated
using the menu. Refer to
"5. CAMERA SETTINGS
and ADJUSTMENT [Menu
Configuration and content]"
(P81)
for setting.
Reference:
Refer to
"SAFETY
PRECAUTIONS [Regarding
the Fiber Connector and the
Fiber Optic Cable]" (vii)
for
how to handle and secure the
¿EHUFDEOH
