20
i
①
Lens mount
Various 2/3" broadcast HD lenses can be mounted.
②
LENS LOCK lever
Locks the lens mount. Turn the lens mount ring using this lever to secure the lens after the
lens is inserted into the lens mount.
③
MIC button
The intercom microphone is turned ON while this button is pressed.
④
SET button
&RQ¿UPVWKHVHOHFWHGLWHPRUYDOXHRQWKHPHQX
⑤
ROTARY PULSE switch
Selects a shutter speed or other settings on the menu.
⑥
VF CHAR button
While this button is pressed, the camera status and various markers appear on the
YLHZ¿QGHU$OVRXVLQJWKLVEXWWRQZLWKWKH527$5<38/6(VZLWFKZLOOPDNHWKHPHQX
appear or disappear.
⑦
P. FUN C s wit ch
Turns ON/OFF the functions allocated by the user. The user can allocate the following
IXQFWLRQV,5,6&255,5,6&255$872.1((6.,1'7/62)7'7/DQG
SCENE FILE
 21 7XUQV21WKHDOORFDWHGIXQFWLRQ
 2))7XUQV2))WKHDOORFDWHGIXQFWLRQ
 6(/6HWWKLVVZLWFKWR6(/ZKHQDOORFDWLQJWKHIXQFWLRQ
⑧
LENS connector
&RQQHFWVDSLQOHQVFDEOH,WLVFRPSDWLEOHZLWK%7$VSHFOHQVHV
⑨
Cable clamp
Secures the microphone cable and lens cable (pigtail cable).
Reference:
Refer to
"5. CAMERA
SETTINGS and
ADJUSTMENT [Basic
Operation of the Menu]" (P78)
for how to open and close the
menu.
Reference:
Refer to
"5. CAMERA
SETTINGS and
ADJUSTMENT [Allocating
Functions to the P.FUNC
Switch]" (P76)
for how to
allocate functions to the P.FUNC
switch.
Reference:
Refer to
"7. SPECIFICATIONS
[Lens Connector]" (P125)
for the pin functions of the lens
connector.
