SWIFT K11-EN, Rev.A 15
4.1.3 Battery capacity check
Press and the current remaining amount is displayed.
Remaining battery display
(Monitor)
Remaining battery indicator
(Battery LED)
Remaining
battery
(5 bars)
5 LED
80 ~ 100%
(4 bars)
4 LED
60 ~ 80%
(3 bars)
3 LED
40 ~ 60%
(2 bars)
2 LED
20 ~ 40%
(1 bar)
(No bar)
1 LED
10%
0 LED
No display on LED
5% or none
When the remaining battery is indicated 10% or below, charge the product for use. It may
affect splice quality.
