2. Product specifications and composition
2.1 Product specifications
ITEM
DESCRIPTION
Fiber alignment
IPAAS core to core alignment
(Image pattern analysis alignment system)
Applicable type of fibers
0.25mm, 0.9mm, 2.0mm, 3.0mm, 4.0mm, Indoor cable
Fiber count
Single fiber
Applicable fiber dimensions
Cladding diameter: 80~150 ㎛, Coating diameter: 100 ㎛~4mm
Fiber setting and cleaved length
7~16mm
Splicing modes
Splice mode: 300, Heat mode: 100
Typical splice Loss
SM: 0.02dB, MM: 0.01dB, DS: 0.04dB, NZDS: 0.04dB
Return loss
> 60dB (Typical)
Splicing time
Typical 6sec. (Quick Mode)
Sleeve heating time
9sec (IS-45 Sleeve, IS-45 mode),
13sec (IS-60 Sleeve, IS-60 mode)
Applicable protection sleeve
40mm, 60mm, 32mm or 28mm for SOC
Storage of splice result
The last 10,000 results to be stored in the internal
memory.(Image 10,000 results)
Tension test
1.96N ~ 2.25N
Dimension
143(W) x 163(L) x 140(H)mm (Without Bumper)
Weight
With battery 2.25kg
Viewing method and display
Two CMOS cameras and 5.0-inch color touch LCD
Fiber view and magnification
X/Y : 200X, Max 400X
Power supply
DC Lithium polymer battery (DC 14.8V, 4700, 6000mAh-option),
100~240V AC Adapter
No. of splice cycles with battery
Typical 250 cycles/ More than 300 cycles(K11-6000)
Electrode life
More than 3,500 times
Terminals
USB
