SWIFT K11-EN, Rev.A 28
5.2.2 Cutter blade rotation
When cutter fails to cut optical fiber properly, rotate the blade as follows.
i. Unscrew the right and the left clamp screw using 1.5 hex key wrench.
ii. Rotate the blade one gauge only with a soft cotton swab. (Blade is of 16 gauges in total.)
iii. Tighten the right and the left clamp screw using 1.5 hex key wrench.
