C.2.2.7 Illumination
Illumination allows selecting from four different illumination settings for the scan
sequence.
Picture 26: Illumination modes
Default: Scans with default illumination setting. This setting is recommended for flat
documents without a surface structure.
Top: The resulting image shows the object as illuminated from the top side.
Bottom: The resulting image shows the object as illuminated from the bottom side.
3D Light: The resulting image shows the surface of the scanned object with a 3D effect.
This improves the results while scanning objects with a relief-like surface. For
example coins or objects with imprinting.
C.2.2.8 Stitching
Stitching allows selecting one of two stitching methods.
Picture 27: Available stitching methods
The default setting is Adaptive 2D.
None: Select this setting when scanning plain documents with the paper
transport wings inserted.
Adaptive 2D Default setting.
Select this setting when scanning documents with uneven structured
surface, e.g. multiple folded papers. The image data will be merged
dynamically. The time until the image is displayed will increase a little.
