Page 86 Manual
C.6 Touchscreen Viewer&Job Control
The Viewer Control screen allows the operator to control and modify the image on the
external TFT flat screen (option). Use the video connector (Picture 6, # 4) to connect an
external monitor to the scanner.
Picture 89: Viewer & Job Control screen
The preview section (1) represents the TFT flat screen.
The scanned image is displayed on the TFT flat screen and with reduced quality in the
preview section right beside the controller elements.
Picture 90: Scanned image in preview area
The ICC Profile checkbox allows activating the ICC profile for the
external monitor.
Previously an ICC file must be uploaded to the scanner. Uploading
is done in the Scan2Net interface, setup level Poweruser.
(1)
