2. DESCRIPTION OF CONTROLS
2.1 Description of reception Base in radio frequency.
e radio frequency reception Base is a device, which allows
heating unit to be controlled by means of programs, settings
and modes determined by the associated CAR
V2
.
2.2 Base Signals.
e two LEDs on the Base (1 and 3 Fig. 2-1) indicate the
operating status of the Base according to the table below.
State Le LED (1) Right LED (3)
No synchronisation
3 ash every
2 s
o
Synchronisation
activated
(normal operation)
1 ash every
2 s
1 ash every
60 s
Association phase
0.5 s On,
0.5 s O
for 10 s
o
No communication
between the Base and
CAR
V2
3 ashes
every 2 s
o
No communication
between the Base and
the boiler
2 ashes
every 2 s
1 ashes
every 60 s
Test
ashes
synchronised
with right
LED (5/s)
ashes
synchronised
with le
LED (5/s)
Forcing manually
3 ashes
every 2 s
3 ashes
every 2 s
Info search from
CAR
V2
o
1 ash
every 2 s
Key:
1 - Le LED
2 - TEST mode key
3 - Right LED
Fig. 2-1
