34
INSTALLERUSERMAINTENANCE TECHNICIAN
Id
Parameter
Parameter Description Range Default
Customised
value
P0
Max DHW
output
Denes the maximum heat output percentage of the boiler during the D.H.W.
phase compared to the maximum heat output available
0 - 100 % 100 %
P1 Min CH output Denes in percentage the minimum output in central heating mode 0 - P2 0 %
P2 Max CH output
Denes the maximum heat output percentage of the boiler during the central
heating mode compared to the maximum heat output available
0 - 100 %
G20 = 85
G31 = 82
P3 - Not available for this model - -
P4
Pump function-
ing
e pump can function in two ways.
0 intermittent: in winter "mode" the circulator is managed by the room
thermostat or by the remote control
1 continuous: in "winter" mode the circulator is always powered and is
therefore always in operation
0 - 1 0
P5
External probe
correction
If the reading of the external probe is not correct it is possible to correct it
in order to compensate any environmental factors.
-9 ÷ 9 K 0
P6 - Not available for this model - -
P7 - Not available for this model - -
Id
Parameter
Parameter Description Range Default
Customised
value
t0
Central heating
set point min-
imum temper-
ature
Denes the minimum ow temperature. 20 ÷ 50 °C 25
t1
Central heating
set point max-
imum temper-
ature
Denes the maximum ow temperature.
(t0+5) ÷
85 °C
85
t2 - Not available for this model - -
t3
Domestic hot
water priority
timing
In winter mode the boiler, at the end of a domestic hot water request, is
ready to switch to central heating mode if there is an active request. Timing
sets a time period in which the boiler waits before changing the operating
mode, in order to quickly and comfortably satisfy an additional request for
domestic hot water.
0 - 100
seconds
(step 10 sec)
2
t4
Central heating
ignitions timer
e boiler has electronic timing, which prevents the burner from igniting
too oen in central heating mode
0 - 600
seconds
(step 10 sec)
18
t5
Central heating
ramp timer
In the heating stage, the boiler performs an ignition ramp in order to reach
the maximum output set
0 - 840
seconds
(step 10 sec)
18
t6
CH ignition de-
lay from TA and
CR request
e boiler is set to switch-on immediately aer a request. In the event of
particular systems (e.g. area systems with motorised thermostatic valves
etc.) it may be necessary to delay ignition
0 - 600
seconds
(step 10 sec)
0
t7 Display lighting
Establishes the display lighting mode.
0 : the display lights up during use and lowers aer 15 seconds of inactivity.
In the case of anomaly the display ashes.
1 : display lighting o.
2 : the display is always lit up.
0 - 2 0
t8 Display
Establishes what the indicator displays 19 (Fig. 35).
"Summer" mode:
0: the indicator is always o
1: pump active displays the ow temperature,
pump o the indicator is o
"Winter" mode:
0: always displays the value set on the CH selector
1: pump active displays the ow temperature,
pump o always displays the value set on the CH selector
0 - 1 1
t9
Flow o tempera-
ture increase
Increases the ow o temperature at ignition only in the rst 60 seconds.
Aer the ame is detected, the temperature is increased by t9
0 - 15 0
