INSTALLERUSER
MAINTENANCE TECHNICIAN
48
t6
CH ignition delay
from TA and CR
request
e boiler is set to switch-on immediately aer a request. In the event
of particular systems (e.g. area systems with motorised thermostatic
valves etc.) it may be necessary to delay ignition
0 - 600 seconds
(step 10 sec)
0
t7 Display lighting
Establishes the display lighting mode.
- 0: the display lights up during use and lowers aer 15 seconds of
inactivity. In the case of anomaly the display ashes.
- 1: display lighting o.
- 2: the display is always lit up.
0 - 2 0
t8 Display
Establishes what the indicator displays 19 (Fig. 37).
"Summer" mode:
- 0: the indicator is always o.
- 1: circulator active, it displays the ow temperature,
pump o the indicator is o
"Winter" mode:
- 0: it always displays the value set on the central heating selector
- 1: circulator active, it displays the ow temperature,
pump o always displays the value set on the CH selector
0 - 1 1
t9
Flow o
temperature
increase
Increases the ow o temperature at ignition only in the rst 60 sec-
onds. Aer the ame is detected, the temperature is increased by t9
0 - 15 0
Id
Parameter
Parameter Description Range Default
Cus-
tomised
value
A0 Hydraulic model
Denes the type of hydraulics in the boiler
(0 = instant; 1 = storage tank)
0 - 1 0
A1
Maximum pump
speed
Denes the maximum operating speed of the circulator
(If A1 = A2 circulator operating at set speed)
A2 - 9 9
A2
Minimum pump
speed
Denes the minimum operating speed of the circulator 1 - A1
Victrix Tera 28 1
6
Victrix Tera 32 1
5
Victrix Tera 38 1
5
A3
Pump operating
mode
Sets the pump operating mode
- DELTA T = 0: proportional head (see parag. 1.28)
- DELTA T = 5 - 25 K: ∆T constant (see Parag. 1.28)
0 - 25 15
A4
Storage tank ow
oset
Establishes the temperature to be added to the DHW set-point to cal-
culate the ow set to heat the storage tank (only useful with a coupled
storage tank and parameter A0=1).
5 - 50 °C 25
A5
Storage tank
activation oset
Temperature value to be subtracted from the DHW set-point to cal-
culate the boiler ignition to heat the storage tank (only useful with a
coupled storage tank and parameter A0=1).
0 - 15 °C 3
A6 DHW thermostat
Establishes the switch-o method in DHW mode.
- 0 Fixed: the switch-o temperature is xed at the maximum value
regardless of the value set on the control panel.
- 1 Correlated: the boiler switches o according to the temperature
set.
0 - 1 0
