Before Using the Inverter 1-2
1
(1-2) Overall view (5.5,7.5kW)
(2-1) View of wiring part(4.0kW or below)
A barrier is provided in the main circuit terminal
block cover for the P1, P (+), DB and N (-) cable
port. Cut the barrier before wiring.
Keypad panel mounting screw
Keypad panel
Intermediate cover
Ratings nameplate
Terminal block cover
Control cable port
P1, P (+), DB,
N (-) cable port
L1/R, L2/S, L3/T
(L1/L, L2/N), U, V, W
cable port
Grounding cable port
