IMO VXSM75-1 - Configuring Inverter Functions; Fundamental Functions (F Group)

Description of change during operation
: The data changed by the or key
takes effect on the inverter operation.
However, press the key to store the new
data.
Selecting Functions 5-1
5
V
V
5. Selecting Functions
5-1 Function Selection List
Table 5-1-1 Function selection list
F: Fundamental functions
Min. Factory
Name Setting range unit setting
F00 Data protection 0: Data change enabled
1: Data protected 1 0 X 0
F01 Frequency 0: Keypad operation
command 1 1: Voltage input (terminal 12)
2: Current input (terminal C1)
3: Voltage and current input
4: Voltage input with polarity (terminal 12) 1 0 x 0
5: Voltage input inverse mode
operation (terminal 12)
6: Current input inverse mode
operation (terminal C1)
7: UP/DOWN control mode 1
8: UP/DOWN control mode 2
F02 Operation method 0: Keypad operation (direction of
rotation: input at terminal block)
1: External signal (digital input) 1 2 x 0
2: Keypad operation (forward rotation)
3: Keypad operation (reverse rotation)
F03 Maximum frequency 1 50 to 400 Hz 1Hz 50 x 0
F04 Base frequency 1 25 to 400 Hz 1Hz 50 x 0
F05 Rated voltage 1 0V : Voltage proportional to the
(at Base frequency1) source voltage is output.
80 to 240V(200V class) 1V 230 X 0
160 to 480V(400V class) 1V 400
F06 Maximum voltage 180 to 240V(200V class) 1V 230 X 0
(at Maximum 160 to 480V(400V class) 400
frequency 1)
F07 Acceleration time 1 0.01 to 3600 s 0.01s 6.00 6
F08 Deceleration time 1 0.01 to 3600 s 0.01s 6.00 6
F09 Torque boost 1 0: Automatic torque boost
1: Square reduction torque characteristics
2: Proportional torque characteristics 1 0 0
3 to 31: Constant torque characteristics
F10 Electronic thermal 0: Inactive
overload relay 1: Active (for general purpose motors) 1 1 0
for motor 1 (Select) 2: Active (for forced-ventilated motors)
F11 (level) 20 to 135% of the rated inverter current 0.01A
rated
motor current 6
F12
(Thermal time constant) 0.5 to 10.0 min. 0.1min 5.0 2
Function code
Change during operation
RS485 Data format
User setting
: Press the or key to change the
data. The new data takes effect after the
key is pressed to store the data.
X : The data can be changed only while the
inverter is stopped.
V
V
FUNC
DATA
FUNC
DATA
