Name Setting range unit setting
F13 Electronic thermal 0: Inactive
overload relay 1: Active (for external braking resistor
(for braking resistor) DB__-2C/4C) 1 0 X 0
2: Active (for external braking resistor
TK80W : 0.1 to 2.2E11S-7
DB__-4C : 0.4 to 7.5E11S-4)
F14 Restart mode 0:Inactive (The inverter immediately
after momentary trips upon power failure.)
power failure 1:Inactive (The inverter trips after the
power failure is recovered.)
2:Active (The inverter restarts at the 1 0 X 0
frequency effective at the time of
power failure.)
3:Active (The inverter restarts at the
starting frequency.)
F15 Frequency limiter
(High) 0 to 400 Hz 1Hz 70 0
F16 (Low) 0 0
F17 Gain
(For frequency setting
signal) 0.0 to 200.0% 0.1% 100.0 2
F18 Bias frequency -400 to +400Hz 1Hz 0 1
F20 DC brake
(Starting frequency) 0.0 to 60.0Hz 0.1Hz 0.0 2
F21 (Braking level) 0 to 100% 1% 0 0
F22 (Braking time) 0.0 s (Inactive)
0.1 to 30.0s 0.1s 0.0 2
F23 Starting frequency
(Freq.) 0.1 to 60.0Hz 0.1Hz 0.5 X 2
F24 (Holding time) 0.0 to 10.0s 0.1s 0.0 X 2
F25 Stop frequency 0.1 to 6.0Hz 0.1Hz 0.2 X 2
Motor sound
(Carrier frequency) 0.75,1 to 15kHz 1kHz 15 0
(Sound tone) 0 to 3 1 0 0
5-2 Selecting Functions
5
Description of change during operation
: The data changed by the or key takes
effect on the inverter operation. However,
press the key to store the new data.
V
V
Function code
Change during
operation
RS485 Data format
: Press the or key to change the data.
The new data takes effect after the key is
pressed to store the data.
X : The data can be changed only while the
inverter is stopped.
V
V
FUNC
DATA
FUNC
DATA
User setting
