IMO VXSM75-1 - Page 24

Installation and Connection 2-10
2
Inverter type Main circuit terminal drawing
VXSM550-3
VXSM750-3
Screw size : M5
Tightening torque : 3.5N
.
m
G G
L1/R L2/S L3/T DB P1 P(+) N(-) U V W
(1) Main circuit terminal block(Continued)
(2) Control terminal block
Screw size: M2.5
Tightening torque: 0.4N◊m
30A 30B Y1E C1 FM X1 X2 X3 X4 X5 CM
30C Y2E CMC 11 12 13 CM FWD REV CM P24
