NanoPhotometer
®
P-Class User Manual
Version 2.1 Page 32 / 70
Calibration Screen (manual entry)
Results screen
Calibration Screen (manual entry)
Shows previously entered calibration values and allows
values to be entered via the keypad.
Step 22 The highlighted box can be edited in order to enter an
absorbance value corresponding to a given
concentration value using the keypad numbers. Range
is 0.001 to 9,999. Use C to backspace and clear the last
digit entered and the up and down arrows to move
between boxes.
Step 23 Press OK to accept the calibration and go to the
Results screen (see below) OR press Back to return
to the Standards screen.
Results screen
Step 24 Insert the reference sample and press Blank key. This
will be used for all subsequent samples until changed.
Step 25 Insert the sample and press Sample . The
concentration of the sample is taken and displayed.
Step 26 Repeat for all samples.
Step 27 Press Menu/Options to display available Options which
are described below press Escape and confirm with
OK to return to the Protein folder. Query needs
confirmation to avoid unintended escaping the
application.
NanoPhotometer
®
P 300
Options (select using key pad numbers)
NanoPhotometer
®
P 330 / P360
Menu (select using key pad numbers)
Options (select using key pad numbers)
1) Return to parameters screen.
2) Print result via selected method.
3) Toggle graph on/off. Displays the calibration graph, cursors
give values for last measured sample.
7) Sample number – add a prefix to the sample number and
reset the incrementing number to the desired value.
8) Save method – use the left and right arrows to select a folder
to store in (User Methods 1-9), press the down arrow and enter
name.
9) Open printer settings, possibility to change the printer settings
within the method as described in 7.3 Output Options / Printer
Exit Options by pressing Escape , or wait.
Menu (select using key pad numbers)
1) Return to parameters screen.
2) Transfer the results via selected Output Options.
7) Sample number – add a prefix to the sample number and
reset the incrementing number to the desired value.
8) Save method – use the left and right arrows to select a folder
to store in (User Methods 1-9), press the down arrow and enter
name.
9) Open Output Options settings, possibility to change the Output
settings within the method as described in 7.3 Output Options
/ Printer
Exit Menu by pressing Escape , or wait.
