IMT Analytics FlowAnalyser PF-300 PRO - Page 23

Start-up
23
5
IMT Analytics AG
5.4.3 External trigger
The external trigger interface is used to start and stop volume measurement and to
determine ventilation parameters using an external signal. The input is electrically
isolated.
Maximum 24V and 60 mA to be used on external trigger interface.
5.4.4 USB
The USB host connector can be used to connect a memory stick for data logging
and also for firmware upgrade.
