MultiGasAnalyser OR-703
39
8
IMT Analytics AG
Physical data Dimensions (L × W × H) 38 × 37 × 34 mm
1.49 × 1.45 × 1.34 inches
Weight <25 g (not including cable)
Cable length 2.50 m ± 0.1 m
Ambient conditions Operating temperature 10 – 40 °C, 50 – 104 °F
Storage temperature -40 – 70 °C, -40 – 158 °F
Air humidity (operation) 10 – 95 % RH, non-condensing
Air humidity (storage) 10 – 95 % RH, non-condensing
Atm. pressure (operation) 525 – 1200 hPa (< 5211 m)
Accuracy
specifications
(under standard
conditions)
Gas Area Tolerance
CO
2
0 – 15 vol% ± (0.2 vol% + 2% of reading)
15– 25 vol% unspecified
N
2
O
0 – 100 vol% ± (2% vol% + 2% of reading)
HAL, ISO, ENF
0 – 8 vol% ± (0.15 vol% + 5% of reading)
8 – 25 vol% unspecified
SEV
0 – 10 vol% ± (0.15 vol% + 5% of reading)
10 – 25 vol% unspecified
DES
0 – 22 vol% ± (0.15 vol% + 5% of reading)
22 – 25 vol% unspecified
Rise times
(@ 10 L/min)
CO
2
≤ 90 ms
N
2
O, HAL, ISO, ENF, SEV, DES ≤ 300 ms
Monitoring Numerical measurement data and real time graph representation
with FlowLab software.
Deviations from gas setting stated. For example, 50 vol% helium typically reduces
the CO
2
values by 6 %. This means that a measured mixture consisting of 5.0 vol%
CO
2
and 50 vol% helium is equivalent to a measured concentration of (1 – 0.06) * 5.0
vol% = 4.7 vol% CO
2
.
8.9 Technical specifications
