16 Model 5525-6025-6625 Parts & Specifications Manual Part # 99904215
Test both sides of the truck. If the crane cannot rotate through the yellow zone with at least
one rear tire firmly touching the ground, you must work with IMT for a custom Reduced
Capacity Lift Chart. In this situation, please contact IMT for assistance.
CAUTION
DO NOT LIFT IN THE “NO LIFTING ZONE.”
Follow safe crane practices throughout the testing. Keep the load as close to the ground as
possible.
The minimum 90° “No Lifting Zone” over the cab must be on ALL Reduced Capacity Load
Charts. The zone may need to be increased if front stabilizers are not used. In addition, the
stability may be greater on one side of the unit than the other, but IMT has chosen to keep
both ratings the same. Thus, the lowest stability percentage is reported for each side.
Install the RCLC decal on the inside of the crane compartment door.
Keep a record of the reduced stability test to verify the decals in case replacement is
necessary.
