3 Technical Data
MC60V
Crucible volume
50 cm³ (practically 38 cm³)
Pressure range in melting cham-
ber in bar
-1 to 2
Crucible temperature in °C
max. 1300
Melting performance in kW
3.5
Mains supply
230 V, 50 or 60 Hz
Fuse protection in A
16
Abduct current in mA
4.45
Thermocouple
Type N (NiCr-Ni), max. 1300 °C
Cooling water supply
Øa 6 mm, 2.5 - 5 bar /
min. 1.5 liter/minute, max. 6 °dH
Cooling water recoil
Øa 6 mm, pressureless, maximum 70 °C (158
°F)
Cooling water entry temperature
15 - 25 °C / 59 - 77 °F {to prevent condensation:
20 - 25 °C / 68 – 77 °F}
Ambient temperature
10 - 35 °C / 50 - 95 °F
Relative humidity
20 - 80 %
Protective gas supply
Øa 8 mm, argon or nitrogen, 6-8 bar
Vacuum
Øa 8 mm, min. 8 m³/h, 0.1 mbar abs.
Weight in kg
ca. 32
Dimensions in mm
(Wide x Depth x Height)
400 x 450 x 450
Maximum melting temperature
type N (NiCr-Ni): 1300 °C
Noise emission in dB (A)
72
