tina46e1-b (2017-12) BPG402.om 25
Connect the power supply to the gauge and lock the connector with the
screws.
Connect the RS232C line to the instrument or control device and lock the
connector with the screws.
RS232C
PC
BPG402-Sx
Power supply
Mains
Connect the power supply to the mains.
Connecting the power supply
