User Manual 4-2 V2.1
TriBoard TC3X7 TH V2.0(1) and TriBoard TC3X7 V2.0 2018-10
TriBoard Manual TC3X7
Hardware: TriBoard TC3X7 TH V2.0(1) and TriBoard TC3X7 V2.0
TriBoard Configuration
4.2 Assembly Options
4.2.1 General optional resistors
Note: All resistors are red marked in the following figures.
Table 4-2 General optional resistors (default assembly in brackets)
Component Description
R202 Connect P20.2 (/TESTMODE) to GND (not assembled)
R203 XTAL1 Rload (50 Ohm) (not assembled)
R206 XTAL Rparallel (not assembled)
R207 XTAL2 Rserial (assembled)
R238 Switch off EVRC (not assembled)
R240 Switch off EVR33 (not assembled)
R390 Connect V_STBY to toggle LEDs D302...D305 (assembled)
R399 Connect V_UC to toggle LEDs D306...D309 (assembled)
R423 Connect P20.0 with miniWiggler JDS (not assembled)
R424 Connect P20.0 with OCDS1 connector (not assembled)
R425 Connect P20.1 with OCDS1 connector (not assembled)
R426 Connect P20.2 with OCDS1 connector (not assembled)
R427 Connect P20.1 with USR1 of miniWiggler JDS (not assembled)
R428 Connect P20.2 with USR1 of miniWiggler JDS (not assembled)
R429 Connect P21.6 (DAP3) with USR1 of DAP (assembled)
R430 Connect P20.2 with USR1 of DAP (not assembled)
R433 Connect P20.1 with ETK connector (not assembled)
R439 Connect P21.7 with ETK connector (not assembled)
R508 Connect pin MPS of TLF35584 to V_CO (assembled)
R524 Connect VDDP3 to V_UC (not assembled)
R525 Connect VDDP3 to +3V3 (not assembled)
