User Manual 6-5 V2.1
TriBoard TC3X7 TH V2.0(1) and TriBoard TC3X7 V2.0 2018-10
TriBoard Manual TC3X7
Hardware: TriBoard TC3X7 TH V2.0(1) and TriBoard TC3X7 V2.0
Connector Pin Assignment
6.7 LIN connector pinout
Figure 6-7 LIN connector pinout (IDC10)
6.8 HSCT connector pinout
Figure 6-8 HSCT connector pinout (IEE1394 6-conductor)
6.9 Ethernet connector pinout
Figure 6-9 Ethernet connector pinout (RJ45)
2 468
GND
BUS
VIN opt
13579
1
0
GND
3
6
2
TXD_P
RXD_P
15
4
GND
GND
TXD_N
RXD_N
SYSCLK
J2
J1
J3
J4
J5
J6
J7
J8
