Infineon TriBoard TC3X7 Series User Manual

User Manual 6-4 V2.1
TriBoard TC3X7 TH V2.0(1) and TriBoard TC3X7 V2.0 2018-10
TriBoard Manual TC3X7
Hardware: TriBoard TC3X7 TH V2.0(1) and TriBoard TC3X7 V2.0
Connector Pin Assignment
6.3 Power connector pinout
Figure 6-3 Power connector pinout (Roka 520 2550
6.4 USB connector pinout
Figure 6-4 USB connector pinout (Micro USB B-type)
6.5 FlexRay™ (ERAY) connector pinout
Figure 6-5 FlexRay™ (ERAY) connector pinout (IDC10)
6.6 CAN connector pinout
Figure 6-6 CAN connector pinout (IDC10)
+3,5V...40V
GND
D+ D-
VCC
GND
ID
2 468
GND
BP
BM
13579
1
0
2 468
GND
CANH
CANL
13579
1
0
GND
