Infineon TriBoard TC3X7 Series - Layout with Dimensioning

User Manual 7-11 V2.1
TriBoard TC3X7 TH V2.0(1) and TriBoard TC3X7 V2.0 2018-10
TriBoard Manual TC3X7
Hardware: TriBoard TC3X7 TH V2.0(1) and TriBoard TC3X7 V2.0
Schematic and Layout
7.4 Layout with Dimensioning
The following dimensions should be used for development of extension boards.
Figure 7-10 Dimensioning (mm)
TriBoard-TC3X7 (TH) V2.0(1)
INFINEON TECHNOLOGIES AG
