User Manual 4-4 V2.1
TriBoard TC3X7 TH V2.0(1) and TriBoard TC3X7 V2.0 2018-10
TriBoard Manual TC3X7
Hardware: TriBoard TC3X7 TH V2.0(1) and TriBoard TC3X7 V2.0
TriBoard Configuration
4.2.2 Resistors for peripherals
Table 4-3 Resistors for peripherals (default assembly in brackets)
Component Description
R220 Connect V_VR with VDDM (assembled)
R221 Connect +3V3 with VDDM (not assembled)
R222 Connect VAREF1 with VDDM (assembled)
R223 Connect VAREF2 with VDDM (assembled)
R301 Connect P20.7 with RXD of CAN0 transceiver (assembled)
R302 Connect P20.8 with TXD of CAN0 transceiver (assembled)
R303 Connect P14.1 with RXD of CAN0 transceiver (not assembled)
R304 Connect P14.0 with TXD of CAN0 transceiver (not assembled)
R311 Connect P23.0 with RXD of CAN1 transceiver (assembled)
R312 Connect P23.1 with TXD of CAN1 transceiver (assembled)
R313 Connect P00.1 with RXD of CAN1 transceiver (not assembled)
R314 Connect P00.0 with TXD of CAN1 transceiver (not assembled)
R320 Connect P14.10 with TXD of ERAY-A transceiver (assembled)
R321 Connect P14.9 with TXDEN of ERAY-A transceiver (assembled)
R322 Connect P14.8 with RXD of ERAY-A transceiver (assembled)
R323 Connect P32.3 with EN of ERAY-A transceiver (assembled)
R324 Connect P32.2 with ERRN of ERAY-A transceiver (assembled)
R325 Connect P02.1 with RXD of ERAY-A transceiver (not assembled)
R326 Connect P02.4 with TXDEN of ERAY-A transceiver (not assembled)
R327 Connect P02.0 with TXD of ERAY-A transceiver (not assembled)
R328 Connect P10.2 with EN of ERAY-A transceiver (not assembled)
R329 Connect P10.1 with ERRN of ERAY-A transceiver (not assembled)
R340 Connect P14.5 with TXD of ERAY-B transceiver (assembled)
R341 Connect P14.6 with TXDEN of ERAY-B transceiver (assembled)
R342 Connect P14.7 with RXD of ERAY-B transceiver (assembled)
R343 Connect P20.10 with EN of ERAY-B transceiver (assembled)
R344 Connect P20.9 with ERRN of ERAY-B transceiver (assembled)
R348 Connect P15.4 with SCL of I2C Eeprom (assembled)
R349 Connect P15.5 with SDA of I2C Eeprom (assembled)
R364 Connect P15.1 with RXD of LIN1 transceiver (assembled)
R365 Connect P15.0 with TXD of LIN1 transceiver (assembled)
R310 Connect P11.5 with CLOCKOUT of Ethernet PHY (assembled)
R370 Connect P11.12 with RXC of Ethernet PHY (assembled)
R371 Connect CLKOUT of Ethernet PHY with TXC of Ethernet PHY (not assembled)
R372 Connect P11.11 with RXCTL of Ethernet PHY (assembled)
R373 Connect P11.4 with TXC of Ethernet PHY (assembled)
