User Manual 5-2 V2.1
TriBoard TC3X7 TH V2.0(1) and TriBoard TC3X7 V2.0 2018-10
TriBoard Manual TC3X7
Hardware: TriBoard TC3X7 TH V2.0(1) and TriBoard TC3X7 V2.0
Signal (on board used) Description
5.3 Config Signals
5.4 Clock Signals
5.5 Debug Signals
Table 5-3 Config Signals
Short name Description
P14.5 HWCFG1 (EVR33OFF / EVR33ON)
P14.2 HWCFG2 (EVRCOFF / EVRCON)
P14.4 HWCFG6 (Pins in tristate / Pins with pull-up)
P14.3 HWCFG3 (Boot from pins / Boot from Flash BMI)
P10.5 HWCFG4 (see boot configuration Table 4-1)
P10.6 HWCFG5 (see boot configuration Table 4-1)
Table 5-4 Clock Signals
Short name Description
XTAL1 Crystal Oscillator Input
XTAL2 Crystal Oscillator Output
Table 5-5 Debug Signals
Short name Description
/TRST Test Reset
DAP0 Device Access Port Line 0 / Test Data Clock (TCK)
DAP1 Device Access Port Line 1 / Test Data Select (TMS)
DAP2 Device Access Port Line 2 / Test Data Output (TDO)
DAPE0 Device Access Port Line 0 (Emulation part)
DAPE1 Device Access Port Line 1 (Emulation part)
DAPE2 Device Access Port Line 2 (Emulation part)
P21.6 Test Data Input (TDI)
DAP0_A DAP0 / DAPE0 / TCK from debug connectors
DAP1_A DAP1 / DAPE1 / TMS from debug connectors
P21.7 DAP2 / DAPE2 / TDO from debug connectors
P33.6 Device Access Port Line 0 (standby controller)
P33.7 Device Access Port Line 1 (standby controller)
P20.2 Test Mode Select Input
P20.1 TriCore Breakpoint Input
P20.0 TriCore Breakpoint Output
AGBT_CLK_P/_N AGBT Clock Input
AGBT_TX0_P/_N AGBT Transmit Output
AGBT_ERR AGBT Error Output
