User Manual 6-1 V2.1
TriBoard TC3X7 TH V2.0(1) and TriBoard TC3X7 V2.0 2018-10
TriBoard Manual TC3X7
Hardware: TriBoard TC3X7 TH V2.0(1) and TriBoard TC3X7 V2.0
Connector Pin Assignment
6 Connector Pin Assignment
The TriBoard will be shipped with four male (plug) connectors on top layer and four female (socket) connectors
on bottom layer. The default connectors are 80-pol. Board to Board connectors from Samtec:
http://www.samtec.com
Plug:
FTSH-140-02-L-DV-ES-A
Socket:
FLE-140-01-G-DV-A
6.1 On Board only used signals
Following port pins are only used on board and are not connected to any connector also not via resistor:
Table 6-1 On Board only used Signals
Short name Description
P32.0 Used as VGATE1N for EVRC
P32.1 Used as VGATE1P for EVRC
P14.2 Used as HWCFG2 and Slave Select Output (SLSO21) to TLF35584
P14.4 Used as HWCFG6 and Output to Watchdog Input of TLF35584
P14.5 Used as HWCFG1 and E-Ray Channel B Transmit Data Output
P14.6 Used as E-Ray Channel B Transmit Data Output enable
P11.0 Used as Gigabit Transmit Data Output 3 for RGMII
P11.1 Used as Gigabit Transmit Data Output 2 for RGMII
P11.2 Used as Gigabit Transmit Data Output 1 for RGMII
P11.3 Used as Gigabit Transmit Data Output 0 for RGMII
P11.4 Used as Gigabit Transmit Clock Output for RGMII
P11.5 Used as Gigabit Reference Clock input for RGMII (125 MHz high precission)
P11.6 Used as Gigabit Transmit Control Output for RGMII
P11.7 Used as Gigabit Receive Data Input 3 for RGMII
P11.8 Used as Gigabit Receive Data Input 2 for RGMII
P11.9 Used as Gigabit Receive Data Input 1 for RGMII
P11.10 Used as Gigabit Receive Data Input 0 for RGMII
P11.11 Used as Gigabit Receive Data Control Input for RGMII
P11.12 Used as Gigabit Receive Clock Input for RGMII
