Infineon TriBoard TC3X7 Series User Manual

User Manual 5-3 V2.1
TriBoard TC3X7 TH V2.0(1) and TriBoard TC3X7 V2.0 2018-10
TriBoard Manual TC3X7
Hardware: TriBoard TC3X7 TH V2.0(1) and TriBoard TC3X7 V2.0
Signal (on board used) Description
5.6 Peripheral Signals
Table 5-6 Peripheral Signals
Short name Description
P14.1 ASCLIN0 Receive Input A
CAN01 Receive Input B (optional)
P14.0 ASCLIN0 Transmit Output
CAN01 Transmit Output (optional)
P15.3 ASCLIN0 Receive Input B (optional)
P15.2 ASCLIN0 Transmit Output (optional)
P15.1 ASCLIN1 Receive Input A
P15.0 ASCLIN1 Transmit Output
P15.4 I2C0 Serial Clock
P15.5 I2C0 Serial Data Input C und Output
P20.7 CAN00 Receive Input B
P20.8 CAN00 Transmit Output
P23.0 CAN10 Receive Input C
P23.1 CAN10 Transmit Output
P00.1 CAN10 Receive Input A (optional)
P00.0 CAN10 Transmit Output (optional)
P14.10 E-Ray Channel A Transmit Data Output
P14.9 E-Ray Channel A Transmit Data Output enable
P14.8 E-Ray Channel A Receive Data Input 0
P32.3 E-Ray Channel A Enable Output
P32.2 E-Ray Channel A Error Input
P14.5 E-Ray Channel B Transmit Data Output
P14.6 E-Ray Channel B Transmit Data Output enable
P14.7 E-Ray Channel B Receive Data Input 0
P20.10 E-Ray Channel B Enable Output
P20.9 E-Ray Channel B Error Input
P02.0 E-Ray Channel A Transmit Data Output (optional)
P02.4 E-Ray Channel A Transmit Data Output enable (optional)
P02.1 E-Ray Channel A Receive Data Input 2 (optional)
P10.2 E-Ray Channel A Enable Output (optional)
P10.1 E-Ray Channel A Error Input (optional)
TXD3 Ethernet TXD3 Output (P11.0)
TXD2 Ethernet TXD2 Output (P11.1)
TXD1 Ethernet TXD1 Output (P11.2)
TXD0 Ethernet TXD0 Output (P11.3)
TXCLK Ethernet TXCLK Output (P11.4)

Infineon TriBoard TC3X7 Series Specifications

General

Manufacturer	Infineon
Series	TriBoard TC3X7
Clock Speed	300 MHz
Flash Memory	Up to 8MB
Target Application	Automotive, Industrial
Debug Interface	JTAG, DAP
Core Architecture	TriCore
Interface	Ethernet, CAN, LIN, SPI, I2C
Microcontroller	AURIX™ TC3x7
