InfiNet Wireless Quick Start Guide
Copyright © 2004-2009 by InfiNet Wireless Limited.
I. Getting Started
This document is designed to help engineers/technicians in rapid configuring of
InfiNet Wireless R5000 system. The document includes detailed instructions for
first configuration steps and configuration scenarios for typical network
topologies.
1. Scope of document
This document consists of the following chapters:
Getting started
This chapter includes the information about this document purpose and structure.
Getting access to the router
The chapter describes how to get access to the router via Console Port and to
configure Ethernet port.
Point-to-point configuration
This chapter includes a comprehensive list of instructions for point-to-point link
configuration including providing LAN connectivity.
Other topologies
The chapter briefly describes the difference between configuring PTP links and
networks with other topologies.
Performing outdoor testing
The chapter contains a list of requirements for outdoor testing. Also a basic steps
for link improvement and antenna alignment is presented.
2. Abbreviations
The following abbreviations are used in this document:
• BS – Base Station
• CPE – Customer Premises Equipment (also called subscriber or
subscriber unit)
• ODU – Outdoor Unit
• IDU – Indoor power supply Unit
• RF cable – Radio Frequency cable to connect ODU and antenna
• LOS – Line-of-Sight
• STP cable – Shielded Twisted Pair cable to connect ODU and IDU
(relevant for 5000-O and 5000-M modifications). FTP (Foiled Twisted
Pair) CAT5e also can be used
• PTP – Point-to-Point topology
• PTM – Point-to-Multipoint topology
• MINT – Mesh Interconnection Networking Technology
